Ceramic Membrane

Ceramic membranes for micro-, ultra- and nanofiltration

Apply to:

	Membrane Material	Pore Size	Cut-off	Porosity
Microfiltration inopor^® mikro	α-Al₂O₃	800 nm 600 nm 400 nm 200 nm 100 nm 70 nm		40 % - 55 %
	TiO₂	800 nm 400 nm 250 nm 200 nm 100 nm
	ZrO₂	110 nm
Ultrafiltration inopor^® ultra	γ-Al₂O₃	10 nm 5 nm	20 kDa 7500 Da	30 % - 55 %
	TiO₂	30 nm 10 nm 5 nm	100 kDa 20 kDa 8.5 kDa
	ZrO₂	3 nm	2 kDa
Nanofiltration inopor^® nano	SiO₂	1,0 nm	600 Da	30 % - 40 %
Nanofiltration inopor^® nano	TiO₂	1,0 nm 0.9 nm LC²	750 Da 450 Da 200 Da	30 % - 40 %

Membrane material	Pore Size	Porosity
α-Al₂O₃	200 nm-S 100 nm-S 70 nm-S	40 % - 55 %
